The cuboid bone is a short bone in the lateral part of the foot, located on the distal row of the tarsal bones. It is square shaped, hence the name, and is the main bone of the mid foot, due to the several articular surfaces it possesses. Another key function of the cuboid is that it acts as a pulley to the peroneus longus tendon, which lies between the calcaneus proximally and the fourth and fifth metatarsals distally.

Recommended video: Cuboid
Anatomy and function of the cuboid bone.


The cuboid articulates with four bones of the foot:

  • the calcaneus posteriorly
  • the lateral cuneiform medially
  • the fourth metatarsal anteromedially
  • the fifth metatarsal anterolaterally

On occasion there may be a fifth facet for articulation with the navicular, with research suggesting that this cubo-navicular joint occurs in a quarter of ‘normal’ feet. The likelihood of a cubo-navicular joint being present is increased in over-pronated feet.

To provide articulation with the calcaneus, the navicular has a large triangular proximal surface. The cuboid has a distal convex surface, with a medial quadrilateral facet for articulation with the fourth metatarsal, and a larger facet for articulation with the fifth metatarsal. There is a large oval facet medially for articulation with the lateral cuneiform. On the occasions where there is a navicular facet, it is small and oval, just behind the larger lateral cuneiform articulation.

Bony Landmarks

The dorsal surface, directed upward and lateralward, is rough, for the attachment of ligaments.

The plantar surface presents in front a deep groove, the peroneal sulcus, which runs obliquely forward and medialward; it lodges the tendon of the peroneus longus, and is bounded behind by a prominent ridge, to which the long plantar ligament is attached.

The lateral surface presents a deep notch formed by the commencement of the peroneal sulcus.

Cuboid bone - lateral-right view

Cuboid bone - lateral-right view

The posterior surface is smooth, triangular, and concavo-convex, for articulation with the anterior surface of the calcaneus; its infero-medial angle projects backward as a process which underlies and supports the anterior end of the calcaneus.

The anterior surface, of smaller size, but also irregularly triangular, is divided by a vertical ridge into two facets: the medial, quadrilateral in form, which articulates with the fourth metatarsal and the lateral, larger and more triangular one, which articulates with the fifth metatarsal.

The medial surface is broad, irregularly quadrilateral, and presents at its middle and upper part a smooth oval facet, for articulation with the third cuneiform. Ocassionally, there is a smaller facet behind this for articulation with the navicular. The surface is rough in the rest of its extent, for the attachment of strong interosseous ligaments.

Vascular Supply

Deep branches of the medial and lateral plantar arteries (descending from the posterior tibial artery) supply the cuboid, with the deep venous arch providing venous drainage.

Medial plantar artery - caudal view

Medial plantar artery - caudal view


  • Lateral plantar
  • Sural
  • Deep fibular nerves

Lateral plantar nerve - caudal view

Lateral plantar nerve - caudal view

Cuboid Syndrome

Cuboid syndrome is a commonly misdiagnosed lateral midfoot pain common in athletes. It is thought to arise from the disturbance of the articulatory surfaces and structural congruity of the calcaneocuboid joint.

Symptoms include pain resembling ligament sprain from the calcaneocuboid joint to the fourth and fifth metatarsal joints, sometimes radiating into the foot, with tenderness along the peroneus longus tendon. Cuboid syndrome is associated with several other foot problems, including:

  • subluxed cuboid
  • dropped cuboid
  • locked cuboid
  • peronial cuboid syndrome
  • lateral plantar neuritis

Most of which affect the position and integrity of the cuboid bone.

Therapy includes manipulation of the cuboid bone with medial arch support. As with most syndromes of the foot, due to the delicate balance of the tarsals in relation to one another and the amount of force constantly applied to the area during walking and running, any slight dysfunction can easily onset pain and further problems.

Get me the rest of this article for free
Create your account and you'll be able to see the rest of this article, plus videos and a quiz to help you memorize the information, all for free. You'll also get access to articles, videos, and quizzes about dozens of other anatomy systems.
Create your free account ➞
Show references


  • Anon. (2014). Bones and Joints of the Foot and Ankle Overview. footEducation. (accessed 10th of January of 2015)
  • Sandstring, S. (ed.) (2008) Grey’s Anatomy, 40th edition, London: Churchill Livingstone, Chapter 84 Ankle and Foot, page 1429-1441.
  • Waugh, W. (1957). Partial cubo-navicular coalition as a cause of peroneal spastic flat foot. The journal of bone and joint surgery. 39 (3), 520-523
  • Anon. (2014). Cuboid. anatomyEXPERT. (accessed 10th of January of 2015)
  • DeLisa, J. (2005). Foot Disorders. In: DeLisa, J. Gans, B. Walsh, N.Physical Medicine and Rehabilitation: Principles and Practice. 4th ed. Philadelphia: Lippincott Williams & Wilkins. 873.
  • Durall, C. (2011). Examination and Treatment of Cuboid Syndrome .Sports Health. 3 (6), 514-519.
