Anterior and Lateral Views of the Skull

Contents

Sphenoid Bone

The greater wing of the sphenoid is a structure that extends from the side of the body of the bone to curve backwards and laterally. The most posterior part of this projection is a triangular process that fits neatly into the ridge between the petrous and squamous portion of the temporal bone. The structure contains the foramina for many structures. These include the foramen rotundum for the maxillary branch (CNV/II) of the trigeminal nerve, the foramen ovale which is an oval shaped foramen that allows the mandibular branch (CNV/III) of the trigeminal to pass through together with the accessory meningeal artery. If the foramen ovale represents the straight line of an exclamation point, the foramen spinosum represents the dot. The middle meningeal artery (branch of the maxillary artery) enters the cranial cavity through here (foramen spinosum). An occasional opening in the greater wing is the foramen petrosum which is a small opening between the spinosum and ovale for the lesser petrosal nerve to exit through. The lesser wings of the sphenoid are paired wings that extend from the anterior clinoid process laterally to form the anterior border of the middle cranial fossa. The optic canal travels through the medial portion of the wings, and the sella turcica which contains the pituitary gland sits just behind the clinoid processes. Together with the posterior clinoid process (which arise from the body of the pituitary itself) they make a structure that resembles a ‘four poster bed’ in which the pituitary sits. The origin of the words clinoid and clinical are both ‘klinikē’ which is Greek for ‘bedside’.

Anterior and lateral views of the Skull
Recommended video: Anterior and lateral views of the Skull
Structures seen on the anterior and lateral views of the skull.

Facial Skeleton and Sensory Nerves

The orbital surface of Frontal bone is the anteroinferior most section and gives rise to the roof of the orbital socket. The bone articulates with the zygomatic bone laterally the sphenoid bone deep in the eye socket as well as the ethmoid bone at the deep medial section of the eye socket. The orbital surface of the Zygomatic bone is the lateral rim and border of the orbital socket. The bone articulates medially with the maxilla, superiorly with the orbital process of the frontal bone, and with the sphenoid bone deep in the eye socket. The infraorbital foramina are paired openings that can be located on the malar surface of the maxillary bone and transmits the infraorbital nerve. This nerve is a branch of the maxillary division (CNV/II) of the trigeminal nerve and provides sensory innervation to the lower eyelid and cheek. The mental foramina are paired openings that are located on the anterior most aspect of the mandible and transmit the mental nerve. This provides sensory innervation to the chin area and is a branch of the mandibular division (CNV/III) of the trigeminal nerve. In humans the Glabella is the region found between both eyebrows and refers to both the overlying skin and the underlying bone which is also indented. The bone is the orbital process of the frontal bone in the midline as it articulates with both paired nasal bones. The supraorbital notch transmits the supraorbital nerve which provides sensory innervation to the eyebrow and upper eyelid. The orbital plate of the ethmoid is a thin plate of bone and forms part of the medial part of the eye socket. It is part of the ethmoid bone which is a small unpaired bone which separates the nasal cavity from the brain.

The Zygomatic bone forms part of the lateral orbital rim as well as the lateral part of the orbital socket. The bone articulates with the maxilla inferiorly, the frontal bone superiorly and the sphenoid bone within the eye socket.

Mandible

The mandible is the bone that forms the lower jaw. It consists of various parts including the condyle, which articulates with the temporal bone at the temporomandibular joint, the ramus which forms the posterior border, the body which contains the tooth sockets, and the coronoid process to which the temporalis muscle gains its insertion. The bone contains the mandibular foramen at the inner surface of the ramus of the mandible which allows the inferior alveolar nerve; a branch of the mandibular nerve which is a branch of the trigeminal nerve. It allows the nerve to enter the bone and innervate the lower teeth. The body of the mandible can be described as the main bulk of its structure. It is the horizontal section of the bone which gives rise to the row of inferior teeth. The orbital surface of maxilla is the superior aspect of the bone which gives rise to the medial part of the floor of the orbital socket.

The ramus of the Mandible is a ridge of bone that connects the body of the bone to the condyle. The condyle articulates at the TMJ or Temporomandibular joint. The joint is complex and allows for not only pivot movement for opening and closing, but also some anterior translation. Ligament control the range of the movement in this joint. The anterior nasal spine is the projection of the maxilla anterosuperiorly and forms the bony border inferiorly of the pyriform aperture. The Coronal suture divides the frontal bone from the paired parietal bone inferiorly. It continues laterally until it terminates at the anterior pterion (a region where four cranial bones joint together).

Maxilla and Zygomatic Arches

The maxilla is the bone that forms the upper jaw. The zygomatic process articulates with the zygomatic bone laterally, the frontal process articulates with the nasal bones in the anterior midline, the alveolar process gives attachment to the superior teeth and the palatine process which forms the anterior two-thirds of the hard palate.

The Alveolar process is a thickened ridge of bone that contains the teeth sockets that give rise to the teeth which attach by immovable joints known as gomphosis. The Frontal process of Maxilla is the portion of the bone that ascends lateral to the nasal bones. Along with the lacrimal bone and the ethmoid bone, the bone articulates with the orbital surface of the frontal bone superiorly. The frontal process of Zygomatic is the part of the bone that articulates with the frontal bone. The bone extends superiorly and forms the lateral part of the eye socket. The Temporal process of the Zygomatic bone is the portion of the bone that extends laterally to articulate with the zygomatic portion of the temporal bone. The ring that is formed by these structures allows the passage of the temporalis muscle inferiorly to attach of the coronoid process of the mandible. The Zygomatic process of the Maxilla is the portion of the maxilla that articulates with the zygomatic bone laterally and can be located at the inferior border of the zygomatic bone.

Nasal Skeleton

The Ethmoid bone is a small unpaired bone that separates the brain from the nasopharynx. The cribriform plate of the ethmoid bone transmits the fibres of the olfactory nerve. The crista galli is an upward facing ridge of bone that divides the two halves of the plate. The Frontal bone overlies the frontal lobe of the brain anteriorly and forms the forehead and part of the orbital socket. The bone articulates with the parietal cones posteriorly and the greater wing of the sphenoid bone laterally. The Nasal bones are two small paired structures that form the bony part of the external nose. They articulate with anteroinferior portion of the frontal bone superiorly and the nasal process of the maxillary bone laterally. This is in addition to the opposing nasal bone and the ethmoid bone within the orbit. The bones give attachment to the quadrangular cartilage of the nasal septum and the lateral cartilages that form the lateral part of the nasal bridge.

Other Bones of the Anterior and Lateral Skull

The Parietal bone articulates with the frontal bone anteriorly and overlies the parietal lobe of the brain. It articulates with the occipital bone posteriorly as well as the temporal bone laterally. The Sphenoid bone is a complex bone with many distinctive features. Among these are the paired greater and lesser wings. The greater wing can be seen in the external cranium and articulates with both the frontal and temporal bones at the anterior pterion (which overlies the middle meningeal artery). The greater wings also contain numerous foramina including the superior orbital fissure, the foramen rotunda, the foramen ovale and the foramen spinosum. The lesser wings are defined by the anterior clinoid processes at their posteromedial most point. The lesser wings form the anterior boundary of the middle cranial fossa. The body of the sphenoid bone gives rise to the posterior clinoid processes and anterior to it sits the pituitary lobe (within the sella turcica or ‘Turkish saddle’ it appears to resemble).

The Temporal bone is a complex structure with numerous sections. These include the squamous portion which is similar in structure to other bones of the skull and forms the anterosuperior part of the bone. The outer surface of this portion is convex to allow for the attachment of the temporalis muscle. The mastoid is a significant pyramidal protrusion from the underside of the bone and gives rise to the sternocleidomastoid and splenius capitis and the longissimus capitis. The petrous portion of the bone is a hard pyramidal shaped section of the bone that has a complex structure but essentially contains the organs of hearing. The name ‘petrous’ comes from the latin word ‘petrosus’ which means ‘stone-like’, the tympanic section of the bone surrounds the external auditory meatus and the styloid process.

Get me the rest of this article for free
Create your account and you’ll be able to see the rest of this article, plus videos and a quiz to help you memorize the information, all for free. You’ll also get access to articles, videos, and quizzes about dozens of other anatomy systems.
Create your free account ➞
Show references

References:

  • Frank H.Netter MD: Atlas of Human Anatomy, 5th Edition, Elsevier Saunders, Chapter 1 Head and Neck, Skull: Lateral View, Page 6 to 9 and 15.
  • Chummy S.Sinnatamby: Last’s Anatomy Regional and Applied, 12th Edition, Churchill Livingstone Elsevier, Chapter 8 Osteology of the Skull and Hyoid bone, Page 504 and 510.
  • Richard L. Drake, A. Wayne Vogl, Adam. W.M. Mitchell: Gray’s Anatomy for Students, 2nd Edition, Churchill Livingstone Elsevier, Chapter 8 Head and Neck, Page 878 and 885.
  • Richard L. Drake, A. Wayne Vogl, Adam. W.M. Mitchell: Dorland’s Gray’s Pocket Atlas of Anatomy, Churchill Livingstone Elsevier , Chapter 8 Head and Neck, Page 365.
