Anterior abdominal wall

The anterior abdominal wall forms the anterior limit of the abdominal viscera. It runs, superiorly from the xiphoid process and costal cartilages of the 7th, 8th, 9th and 10th ribs to the iliac crest, inguinal ligament, anterior superior iliac spine, pubic tubercle, pubic crest and pubic symphysis inferiorly.

Generally, from superficial to deep, it is comprised of the skin, superficial fascia (adipose and membranous tissues), deep fascia, layers of muscles, extraperitoneal tissue and the peritoneum. Most of these structures, especially the muscles, span the anterolateral abdominal wall and there is no definite boundary between the anterior and lateral abdominal walls, thus the anterior abdominal wall is sometimes referred to as the anterolateral abdominal wall.

Key facts about the anterior abdominal wall
Boundaries Superior: xiphoid process, costal cartilages of the 7th-10th ribs
Inferior: iliac crest, inguinal ligament, anterior superior iliac spine, pubic tubercle, pubic crest, pubic symphysis

From superficial to deep:
- Skin
- Subcutaneous tissue
- Fascia: Camper's fascia (fatty superficial layer), Scarpa's fascia (deep fibrous layer)
- Muscles: transverse abdominis, internal oblique, rectus abdominis, external oblique, pyramidalis

    - Mnemonic: TIRE Pump
- Transversalis fascia
- Peritoneum

Function Protection of the abdominal cavity; clinical examination by "four region scheme" (upper right, upper left, lower right, lower left quadrants) or "nine region scheme" (middle epigastric, umbilical, suprapubic, right hypochondrium, left hypochondrium, right flank, left flank, right groin, left groin regions)
Clinical relations Tap block, hernias, abdominal incisions, nerve injuries

This article will describe the anatomy and function of the anterior abdominal wall.

Regions and quadrants

The anterior abdominal wall is highly distensible and is involved in various functions ranging from support of movements of the abdominal viscera to protection of the abdominal cavity. It is more flexible than the posterior abdominal wall, and supports lateral bending, flexion, extension or protrusion and twisting. It plays a role in the maintenance of posture, and increases in intra abdominal pressure to support defecation, parturition and micturition.

The anterior abdominal wall is also important because it is used in clinical surface anatomy for the localization of abdominal viscera. For these purposes, the abdominal wall is divisible into four quadrants by two imaginary lines; a midline (vertical) and a horizontal line which passes through the umbilicus. The quadrants are named as follows; the right upper quadrant, left upper quadrant, right lower quadrant and left lower quadrant. This form of dividing the abdomen into four quadrants is known as the four region scheme

Similarly, the anterior abdominal wall can also be divided into nine regions by two imaginary vertical lines called mid-clavicular lines (two vertical lines passing through the midpoint of the clavicle on the left and right side), and two imaginary horizontal lines. These regions are of clinical importance. The mid-clavicular lines extend downwards to reach the mid inguinal point. The superior horizontal line is known as a transpyloric line (or transpyloric plane). This line is so named because of its relation to the pylorus of the stomach. It runs horizontally at the halfway point between the jugular notch and top of the pubic symphysis, passing through the pylorus of the stomach. The lower horizontal line can be drawn to join the tubercles of the right and left iliac crests of the hip bones. It is called the transtubercular plane or intertubercular line (intertubercular plane). Therefore, these four lines divide the anterior abdominal wall and the abdominopelvic cavity into a middle epigastric, umbilical, suprapubic or hypogastric, right hypochondrium, left hypochondrium, right flank (right lumbar), left flank (left lumbar), right groin (right iliac, inguinal) and left groin (left iliac, inguinal) regions. This division of the abdomen into nine regions is aptly known as the nine region scheme.


The layers of the anterior abdominal wall are mentioned below:

Skin and fascia

The skin is the most superficial layer of the anterior abdominal wall. It shows creases which represent the lines of orientation of collagen fibers in the dermis of the skin. These lines are referred to as Langer's lines. The Langer’s lines are of clinical relevance and incisions along them heal faster and better leaving little or no scaring; while those across them leave large and more pronounced scars. In pregnant women, obese people and those with abdominal distention, there are dark elongate lines called stretch marks or striae distansae usually on the umbilical and hypogastric regions. Stretch marks during pregnancy is specifically known as striae gravidarum.

Lying just below the skin are two layers of superficial fascia called Camper’s fascia and Scarpa’s fascia. The Camper’s fascia is a subcutaneous tissue containing variable amounts of fatty tissue. This fatty tissue is generally more in females and also in the right and left lower quadrants. Next to the Camper’s fascia is the Scarpa’s fascia. The Scarpa’s fascia is a membranous fatty layer containing fibrous tissue and very little fat. It runs inferiorly into the lower limbs where it changes its name to the fascia lata of the thigh. It is also continuous with the superficial perineal fascia called Colles’ fascia and also with the fascia which invests the scrotum and penis in males.

Deep to the two superficial fascia are layers of deep fascia. The deep fascia of the anterior abdominal wall directly invests the muscular layers of the anterior abdominal wall. They are made up of elastin fibres, dense fibrous connective tissue and divide the groups of muscles of the anterior abdominal wall into fascial components. Because this layer of fascia contains elastin fibres, it helps the anterior abdominal wall in playing a role in increasing the intra-abdominal pressure to support defecation, parturition and micturition.

Muscular layers

There are five (bilaterally paired) muscles in the anterior abdominal wall. These muscles are arranged into three muscular layers by the deep fascias. However, these muscles extend into the lateral aspects of the abdominal wall and are more precisely referred to as muscles of the anterolateral abdominal wall. Of these five muscles, three are flat. These are: the external oblique muscle, the internal oblique muscle and the transverse abdominal muscle. All three muscles attach anteriorly to a strong sheet of aponeurosis which interlaces at the linea alba (Latin word for: white line). Also, the posterior attachment of these flat muscles are onto another tough tendinous aponeurosis of the rectus muscle. This aponeurosis is called the rectus sheath. The rectus sheath houses the remaining two muscles of the anterior abdominal wall. The remaining two muscles are vertical muscles and they are referred to as the rectus abdominis muscle and the pyramidalis muscle. The following is a short description of these five muscles:

The external oblique muscles are a pair of broad, thin, superficial muscles that lie on the lateral sides of the anterior abdominal wall. The location and structure of the external abdominal obliques gives them many different possible actions. The external obliques get their name from their position in the abdomen external to the internal abdominal obliques and from the direction of their fibers, which run diagonally across the sides of the abdomen. The external abdominal obliques have their origins along the lateral ribs 5 through 12 and insert into the xiphoid process, the pubic tubercle, and the iliac crest of the pelvic bones.

Want to learn the attachments, innervations and functions of the abdominal muscles quickly and effectively? Check out our trunk wall muscle anatomy reference chart.

Their shape is roughly rectangular with the long axis running anterior to posterior along the linea alba. The posterior most fibres form the free posterior border. Above and medial to the pubic tubercle , a small triangular defect in its aponeurosis is termed as superficial inguinal ring. The inferior border of the aponeurosis between the anterior superior iliac spine and pubic tubercle, folds backward and forms the inguinal ligament. The lacunar ligament extends backward and upwards towards pectineal line from the medial end of the inguinal ligament. Muscle fibers in the external obliques run medially and inferiorly from the origins to the insertions across the lateral sides of the abdomen and end just lateral to the rectus abdominis muscles.

Key facts about the external oblique muscles
Origins 5th to 12th ribs
Insertions Linea alba, pubic tubercle, and anterior half of iliac crest
Innervation Intercostal nerves (T7- T11), subcostal nerve (T12), iliohypogastric nerve (L1)
Function Flexion and rotation of the trunk, support and compression of the abdominal viscera
  • The internal oblique muscles lie deep to the external oblique muscles, and they are of the anterior and lateral parts of the abdomen. They originate in the thoracolumbar fascia, anterior two-thirds of the iliac crest, and the Iliopectineal arch and insert into the inferior borders of the lower three ribs and their costal cartilages, linea alba, and aponeurosis of the rectus sheath as well as the conjoined tendon to the pubic crest and pectineal line. Most of its fibres run at a right angle to those of external oblique.
Key facts about the internal oblique muscles
Origins Anterior two-thirds of iliac crest, Iliopectineal arch, thoracolumbar fascia
Insertions Inferior borders of ribs 10-12, linea alba, junction with cremaster muscle, pectinal line of pubis (via conjoint tendon)
Innervation Intercostal nerves (T7- T11), subcostal nerve (T12), iliohypogastric nerve (L1), ilioinguinal nerve (L1)
Function Flexion and rotation of the trunk, support and compression of the abdominal viscera
  • The transverse abdominal muscle lies deep to the internal oblique muscle. It is the deepest of the flat muscles, and originates from the anterior two-thirds of the inner lip of the iliac crest of the pelvic bone, the inner surfaces of the cartilages of the 7th to 12th ribs, the thoracolumbar facia, and interdigitates with the diaphragm. It attaches to the linea alba, pubic crest, pectineal line of the pubis via the cojoint tendon. A conjoint tendon is formed by the joining of the lowest tendinous fibres of the internal oblique and transverse abdominal muscle.
Key facts about the transverse abdominal muscles
Origins 7th to 12th costal cartilages, thoracolumbar fascia, iliac crest, connective tissue deep to lateral third of inguinal ligament
Insertions Linea alba, pubic crest, pectineal line of the pubis via the cojoint tendon
Innervation Anterior rami of T7 to T12 spinal nerves (a.k.a 7th- 11th intercostal nerves and subcostal nerve), Iliohypogastric nerve (L1), Ilioinguinal nerve (L1)
Function Support and compression of the abdominal viscera
  • The rectus abdominis muscles are a pair of long straight muscles which run vertically on each side of the anterior abdominal wall. The term rectus abdominis is the Latin meaning “straight abdominal”, and indicates that the muscle fibers run in a straight vertical line through the abdominal region of the body. They are contained in the rectus sheath. The rectus abdominis muscles are separated at the midline by the linea alba. They extend along the entire length of the abdomen adjacent to the umbilicus. Each muscle consists of a string of four fleshy muscular bodies connected by narrow bands of tendon known as tendinous intersections. These intersections are present usually at three levels: at the level of xiphoid process, the level of umbilicus and midway between them. The muscle originates and extends from the xiphoid process of the sternum and costal cartilages of the 5th to 7th ribs to insert into the pubic bone, particularly from the pubic symphysis, pubic crest, and tubercle.
Key facts about the rectus abdominis muscle
Origins Pubic crest and symphysis
Insertions Xiphoid process and 5th to 7th costal cartilages
Innervation Intercostal nerves (T6- T11), Subcostal nerve (T12)
Function Trunk flexion, compression of abdominal viscera, stability of the pelvis
  • The pyramidalis muscle is a small triangular muscle lying anterior to the rectus abdominis muscle. It is contained in the rectus sheath and originates from the bony pelvis, where it is attached to the pubic symphysis and pubic crest through tendinous fibers. The fibres run superiorly and medially to insert into the linea alba at a point midway between umbilicus and pubis through the anterior pubic ligament. Superiorly, the fleshy portion of the muscle passes upward, diminishing in size as it ascends, and ends by a pointed extremity which is inserted into the linea alba, therefore when it contracts, it tenses the linea alba.
Key facts about the pyramidalis muscle
Origins Pubis and pubic symphysis
Insertions Linea alba
Innervation Subcostal nerve (T12)
Function Tension of linea alba


There is a really easy way to remember all the abdominal muscles if you just memorise the mnemonic  TIRE Pump, where each of the letter in bold corresponds to one of the abdominal muscles:

Transversus abdominis
Internal oblique
Rectus abdominis
External oblique

Rectus sheath

The rectus sheath is a strong fibrous sheath around the rectus abdominis and pyramidalis muscle. It is formed by the decussation of the aponeurotic fibres of the flat abdominal muscles. The linea alba is present between the sheaths of both sides. Along with the muscles, it contains superior and inferior epigastric vessels, anterior rami of the lower six thoracic nerves and lymph vessels.

Nerves and vessels

Superior epigastric artery, a branch of internal thoracic artery , runs in the rectus sheath behind the rectus muscle and supplies it. It ends by anastomosing with the inferior epigastric artery. The Inferior epigastric artery is a branch of external iliac artery and enters the rectus sheath after piercing the fascia transversalis. It runs upwards, supplies the lower central part of anterior abdomen and anastomoses with superior epigastric artery. The lower two posterior intercostal arteries and the deep circumflex iliac arteries also contribute in the arterial supply. There is a network of superficial veins that radiate out from the umbilicus and a few small paraumbilical veins which connect the network. The deep veins follow the arteries of the same name. Muscles of the anterior abdominal wall are supplied by lower six thoracic nerves, the iliohypogastric nerve and the ilioinguinal nerve. The pyramidalis is supplied by 12th thoracic nerve.


There are superficial and deep lymph vessels of the anterior abdominal wall. The superficial lymph vessels above the umbilicus drain into anterior axillary group of lymph nodes and below the umbilicus they drain into superficial inguinal lymph nodes. The deep vessels follow the arteries and drain into internal thoracic, external iliac, posterior mediastinal, and para-aortic (lumbar) nodes.


The external and internal oblique muscles flex the trunk laterally and play their part in rotation. The rectus abdominis muscles help stabilize the pelvis and also flex the trunk. All the muscles of the anterolateral abdominal wall relax the diaphragm as it descends during inspiration which helps the abdominal viscera to accommodate. The muscles pull down the ribs and sternum during coughing and sneezing, and assist in the act of forced expiration. The tone of these muscles supports and protects the abdominal viscera. During the process of micturition, defecation, vomiting and parturition these muscles increase the abdominal pressure (with the glottis of the larynx closed) by contracting together with the diaphragm.

You can use 'image-left' and 'image-right' on images to position them. Upload them with maximum-width of 308px. Infobox Use Heading 2 for the title, and Heading 3 and Normal format for rest Meta content* SEO Seo title* Anterior abdominal wall - Anatomy and Clinical Points Seo description* This article describes the different structures that form the anterior abdominal wall and relevant clinical conditions. Learn this topic now at Kenhub. Cancel

Clinical correlation

Tap Block: This is a peripheral nerve block used to anaesthetize the nerves in the anterior abdominal wall. “TAP” block means transverse abdominis plane block; it is performed by injecting anesthesia on the fascia between the transverse abdominis and internal oblique muscles.

The Retroinguinal Space: The retroinguinal space is a space between the parietal peritoneum and the transversalis fascia. This space can be used for putting a prosthesis when treating an inguinal hernia.

Hernias: Several hernias occur in the anterolateral abdominal wall. These hernias can be umbilical, inguinal and/or epigastric hernias.

  • ​​Inguinal hernia: This occurs when the contents in the abdominal cavity project through an opening on the lower abdominal wall into the inguinal canal. There are two types of inguinal hernias, direct and indirect inguinal hernias.
  • Direct inguinal hernia: Also called acquired inguinal hernia, this type of hernia occurs through a weakness on the abdominal wall and this weakness occurs due to aging over a long period of time. The abdominal viscera and some contents in the abdominal cavity project through an opening on the abdominal cavity and all the contents are held together in a sac formed by the transversalis fascia. The sac projects through the inguinal triangle, the conjoint tendon and the superficial inguinal ring. Direct hernias are more common among males than females.
  • Indirect inguinal hernia: Also called congenital inguinal hernia, this occurs when there is persistent processus vaginalis after the descent of the testis during embryonic development. This hernia is wrapped in a sac formed by the processus vaginalis and it projects through the superficial inguinal ring after leaving the abdominal wall and deep inguinal ring to finally enter the scrotum.

Abdominal Incisions: Incisions on the abdominal wall depend on the type of surgery to be carried out, and the location of the organ (viscera) to be operated on. There are different types of incisions that can be made on the anterolateral abdominal wall. They are:

  • Midline incisions: This is a median or middle incision through the skin and deep through the linea alba down above and below the umbilicus. The incision is usually accompanied by less blood because the linea alba has less blood supply. The advantages of this type of incision is that there is less blood loss and less access to nerves. But the disadvantage of this incision is that the linea alba can easily become necrotized leading to infections.
  • Paramedian incisions: These are incisions made close to and parallel to an imaginary median incision. It is made lateral to the median plane on any side of the anterior abdominal wall. This incision pierces through the rectus sheath and the rectus muscle is shifted laterally to expose the posterior rectus sheath and to avoid incising nerves and vessels. The incisions then goes deep through the posterior sheath into the abdominal cavity. The advantages of this incision is that it gives access to abdominal organs without the stress of trying to avoid the umbilicus (as seen in midline incisions) and it also reduces the risk of developing a hernia. But the disadvantages are more blood loss and more time is spent during surgery.
  • Transverse incisions: This is an incision made transversely or horizontally across the anterior abdominal wall. It includes McBurney, subcostal and Pfannenstiel incisions. This incision pierces through the external and internal oblique muscle, transverse abdominal muscle, rectus abdominal muscle and the linea alba. Transverse incisions are less invasive because they are along the lines of langer’s of skin tension and this helps in lessening scarring and quick healing.

Closing Abdominal Incisions: When closing abdominal skin incisions, the Scarpa’s fascia is sutured because of its tensile strength.

Nerve Injury to the Anterior Abdominal Wall: Nerves such as the ilioinguinal, iliohypogastric and inferior thoracic nerves are prone to injury because they are spread across the anterior abdominal wall. Injury to these nerves results in muscle weakness of the anterior abdominal wall.
